2、产品型号及规格（表1、表2） types(form1 form2) 表1form1
|
型号 type |
名称 name |
|
FZ-VV—0.6/1 |
额定电压0.6/lkV聚氯乙烯绝缘及护会颅制分支电缆 rated voltage0 6/lkV PVCinsulation and sheath pre-fabricated branchcd cable |
|
FZ-ZRVV-0.6/1 |
额定电压0.6/lkV聚氯乙烯绝缘及护套阻燃预制分支电缆 rated voltage 0.6/lkV PVC insulation and sheath flame-retardant pre-fabricated branched cable |
|
FZ-NHVV-0.6/1 |
颧定电压0.6/1 kV聚氯乙烯绝缘及护套耐火预制分支电缆 rated voltage 0.6/lkV PVC insulation and sheath fire-resistant pre-fabricated branched cable |
|
FZ-YJV-0.6/1 |
额定电乐0.6/lkV交联聚乙烯绝缘氯乙烯护套预制分支电缆 rated voltage 0.6/lkV cross-linked polycthylcne insulation and PVC sheath prc- fabricated branched cable |
|
FZ-ZRYJH-0 6/1 |
额定电压0.6/1 kV交联聚乙烯绝缘聚氯乙烯护套阻燃预制分支电缆 rated voltage 0.6/1 kV cross-tinked polyethylene insulation and PVC sheath flame-retardant pre- Fabricated branched cable |
|
FZ-N1HYJV-0.6/1 |
额定电压0.6/lkV交联聚乙烯绝缘聚氯乙烯护套耐火预制分支电缆 rated voltage0.6/lkVcross-linked polyethylene，nsulationandPVCsheathfire-resistant pre-fabricatedbranched cable |
|
FZ-WDYJV-0.6/1 |
颁定电压0.6/lkV交联聚乙烯绝缘聚氯乙烯护套低烟无法，预制分支电缆 rated voltage 0.6/lkV cross-linked polyethylene insulation and PVC sheath LSOH pre- fabricated branched cable |
|
FZ-WDNHYJV-0.6/1 |
额定电压0:6/lkV交联聚乙烯绝缘聚氯乙烯护套低烟无卤耐火预制分支电缆 rated voltageo．6tlkV cross-liriked polyethylene insulation and PVC shea他LSOH fire-resistant pfe- fabricated branChed cahle
|
表2(主干线与表内所列相应的任一支线规格配接)
Form2(main trunk is assorted with any corresponding branch)
|
主干电缆截面 Main cable Section mm2 |
支线缆截面 Branch cable section mm2 |
|||||||||
|
70 95 120 150 185 240 300 400 500 630 |
10 10 10 10 10 10 10 10 10 10 |
16 16 16 16 16 16 16 16 16 16 |
25 25 25 25 25 25 25 25 25 25 |
35 35 35 35 35 35 35 35 35 35 |
50 50 50 50 50 50 50 50 50 |
70 70 70 70 70 70 70 70 |
95 95 95 95 95 95 |
120 120 120 120 120 |
150 150 150 |
185 185 |
3、电缆主要技术参数
3.Cable main technical parameters
0.6/1kV PVC绝缘PVC护套单芯电缆技术参数
0.6/1kV PVC insulation and PVC sheach single-core cable technical parameter
